In Stock
SKU: SENSPD501
Hall Effect Speed Sensor – Short (15/32")
$104.51 NZD inc. GST
Compact 1" anodised aluminium Hall Effect speed sensor designed for tight-space installations where the longer M12 variant won't fit. Detects ferrous teeth or magnets with consistent digital output from near-zero speed up to 15kHz. Wide 5–24V supply range makes it compatible with all major aftermarket ECUs. Includes two nuts for secure panel mounting.
Specifications
- Sensing technology: Hall Effect — digital output
- Thread: 15/32-32
- Overall length: 1" (25.4mm)
- Supply voltage: 5–24V
- Air gap: ~1.5mm from tooth/magnet to sensor
- Frequency range: near zero to 15kHz
- Detection type: ferrous tooth or magnet
- Requires pullup resistor on signal output
- Anodised aluminium housing — includes two nuts
- Compatible with Haltech, Link ECU, MoTeC, Emtron & more
